Simple Kubernetes in Python Monorepos

"Kubernetes, also known as K8s, is an open source system for automating deployment, scaling, and management of containerized applications."
^{(from kubernetes.io)}

Setting up Kubenetes for a set of Microservices can be overwhelming at first sight.

I'm currently learning about K8s and the Ecosystem of tooling around it. One thing that I've found difficult is the actual K8s configuration and how the different parts relate to each other. The YAML syntax is readable, but I also find it hard to understand how to structure it - impossible to edit without having the documentation close at hand. When I first got the opportunity to work with Python code running in Kubernetes, I realized that I have to put extra effort in understanding what's going on in there.

I was a bit overwhelmed by what looked like a lot of repetitive and duplicated configuration. I don't like that. But there's a tool called Kustomize that can solve this, by incrementally constructing configuration objects with snippets of YAML.

Kustomize is about managing Kubernetes objects in a declarative way, by transforming a basic setup with environment-specific transformations. You can replace, merge or add parts of the configuration that is specific for the current environment. It reminds me of how we write reusable Python code in general. The latest version of the Kubernetes CLI - Kubectl - already includes Kustomize. It used to be a separate install.

Microservices

From my experience, the most common way of developing Microservices is to isolate the source code of each service in a separate git repository. Sometimes, shared code is extracted into libraries and put in separate repos. This way of working comes with tradeoffs. With the source code spread out in several repositories, there's a risk of having duplicated source code. Did I mention I don't like duplicated code?

Over time, it is likely that the services will run different versions of tools and dependencies, potentially also different Python versions. From a maintainability and code quality perspective, this can be a challenge.

YAML Duplication

In addition to having the Python code spread out in many repos, a common setup for Kubernetes is to do the same thing: having the service-specific configuration in the same repo as the service source code. I think it makes a lot of sense to have the K8s configuration close to the source code. But with the K8s configuration in separate repos, the tradeoffs are very much the same as for the Python source code.

For the YAML part in specific, it is even likely that the configuration will be duplicated many times across the repos. A lot of boilerplate configuration. This can lead to unnecessary extra work when needing to update something that affects many Microservices.

One solution to the tradeoffs with the source code and the Kubernetes configuration is: Monorepos.

K8s configuration in a Monorepo

A Monorepo is a repository containing source code and multiple deployable artifacts (or projects), i.e. a place where you would have all your Python code and where you would build & package several Microservices from. The purpose of a Monorepo is to simplify code reuse, and to use the same developer tooling setup for all code.

The Polylith Architecture is designed for this kind of workflow (I am the maintainer of the Python tools for the Polylith Architecture).

While learning, struggling and trying out K8s, I wanted to find ways to improve the Configuration Experience by applying the good ideas from the Developer Experience of Polylith. The goal is to make K8s configuration simple and joyful!

Local Development

You can try things out locally with developer tools like Minikube. With Minikube, you will have a local Kubernetes to experiment with, test configurations and to run your containerized microservices. It is possible to dry-run the commands or apply the setup into a local cluster, by using the K8s CLI with the Kustomize configs.

I have added examples of a reusable K8s configuration in the The Python Polylith Example repo. This Monorepo contains different types of projects, such as APIs and event handlers.

The K8s configuration is structured in three sections:

• A basic setup for all types of deployments, i.e. the config that is common for all services.
• Service-type specific setup (API and event handler specific)
• Project-specific setup

All of theses sections have overlays for different environments (such as development, staging and production).

As an alternative, the project-specific configuration could also be placed in the top /kubernets folder.

I can run kubectl apply -k to deploy a project into the Minikube cluster, using the Kustomize configuration. Each section adds things to the configuration that is specific for the actual environment, the service type and the project.

The base, overlays and services are the parts that aren't aware of the project. Those Project-specific things are defined in the project section.

Using a structure like this will make the Kubernetes configuration reusable and with almost no duplications. Changing any common configuration only needs to be done in one place, just as with the Python code - the bricks - in a Polylith Monorepo.

That’s all. I hope you will find the ideas and examples in this post useful.

Resources

• The Python Polylith Example repo
• The Python tools for the Polylith Architecture

^{Top photo by Justus Menke on Unsplash}

Pants & Polylith

But who is Luke and who is R2?

"Pants is a fast, scalable, user-friendly build system for codebases of all sizes"

"Polylith helps us build simple, maintainable, testable, and scalable backend systems"

Can we use both? I have tried that out, and here's my notes.

Why?

Because The Developer Experience.

Developer Experience is important, but what does that mean? For me, it is about keeping things simple. The ability to write, try out and reuse code without any context switching. By using one single setup for the REPL and the IDE, you will have everything at your fingertips.

The Polylith Architecture solves this by organizing code into smaller building blocks, or bricks, and separating code from the project-specific configurations. You have all the bricks and configs available in a Monorepo. For Python development, you create one single virtual environment for all your code and dependencies.

There is also tooling support for Polylith that is useful for visualizing the contents of the Monorepo, and for validating the setup. If you already are into Pantsbuild, the Polylith Architecture might be the missing Lego bricks you want to add for a great Developer Experience.

Powerful builds with Pants

Pantsbuild is a powerful build system. The pants tool resolves all the dependencies (by inspecting the source code itself), runs the tests and creates distributions in isolation. The tool also support the common Python tasks such as linting, type checking and formatting. It also has support for creating virtual environments.

Dude, where's my virtual environment?

In the Python Community, there is a convention to name the virtual environment in a certain way, usually .venv, and creating it at the Project root (this will also likely work well with the defaults of your IDE).

The virtual environment created by Pants is placed in a dists folder, and further in a Pants-specific folder structure. I found that the created virtual environment doesn't seem to include custom source paths (I guess that would be what Pants call roots).

Custom source paths is important for an IDE to locate the Python source code. Maybe there are built-in ways in Pantsbuild to solve that already? Package management tools like Poetry, Hatch and PDM have support for configuring custom source paths in the pyproject.toml and also creating virtual environments according to the Python Community conventions.

^{Note: If you are a PyCharm user, you can mark a folder as a source root manually and it will keep that information in a cache (probably a .pth file).}

Example code and custom scripts

I have created an example repository, a monorepo using Pantsbuild and Polylith. You will find Python code and configurations according to the Polylith Architecture and the Pantsbuild configurations making it possible to use both tools. In the example repo I have added a script that adds source paths, based on the output from the pants roots command, to the virtual environment created by Pantsbuild. This is accomplished by adding a .pth file to the site_packages folder. For convenience, the script will also create a symlink to a .venv folder at the root of the repo.

Having the virtual environment properly setup, you can use the REPL (my favorite is IPython) with full access to the entire code base:

source .venv/bin/activate
ipython

With an activated virtual environment, you can also use all of the Polylith commands:

poly create
poly info
poly libs
poly deps
poly diff
poly check
poly sync

Pants & Polylith

Pantsbuild has a different take on building and packaging artifacts compared to other tools I've used. It has support for several languages and setups. Some features overlap with what's available in the well-known tooling in the Python community, such as Poetry. Some parts diverge from the common conventions.

Polylith has a different take on sharing code, and also have some overlapping features. Polylith is a Monorepo Architecture, with tooling support for visualizing the Monorepo. From what I've learned so far, the checks and code inspection features are the things you will find in both Pants and Polylith.

Pants operate on a file level. Polylith on the bricks level.

My gut feeling after learning about it and by experimenting, is that Pantsbuild and Polylith shares the same basic vision of software development in general and I have found them working really well together. There are some things I would like to have been a better fit, such as when selecting contents of the Pants-specific BUILD files vs the content in the project-specific pyproject.toml files.

Maybe I should develop a Pants Polylith plugin to fix that part. 🤔
How does that sound to you?

Resources

• The Python tools for the Polylith Architecture
• The Pantsbuild website

^{Top Photo by Studbee on Unsplash}

Write Less Code, You Must

An aspect of Python Software Development that is often overlooked, is Architecture (or Design) at the namespace, modules & functions level. My thoughts on Software Development in general is that it is important to try hard writing code that is Simple, and Easy to move from one place to another.

When having code written like this, it becomes less important if a feature was added in Service X, but a better fit would be Service Y when looking at it from a high-level Architectural perspective. All you need to do is move the code to the proper place, and you're all good. However, this will require that the actual code is moveable: i.e. having the features logically separated into functions, modules and namespace packages.

Less Problems

There's a lot of different opinions about this, naturally. I've seen it in in several public Python forums, and been surprised about the reactions about Python with (too) few lines of code in it. How is it even possible having too little of code?

My take on this in general is Less code is Less Problems.

An example

def my_something_function():
    # Validation

    # if valid
    # else do something
    ... python code here

    # Checking

    # if this
    # elif that
    # elif not this or not that
    # else do_something
    ... python code here

    # Data transformation

    # for each thing in the things
    #    do a network call and append to a list
    ... python code here

    # Yay, done
    return the_result

This type of function - when all of those things are processed within the function body - is not very testable. A unit test would likely need a bunch of mocking, patching and additional boilerplate test data code. Especially when there are network calls involved.

My approach on refactoring the code above would be to first identify the different tasks within this controller type of function, and begin by extracting each task into separate functions. Ideally these would be pure functions, accepting input and returning output.

At first, I would put the functions within the same module, close to at hand. Quite quickly, the original function has become a whole lot more testable, because the extracted functions can now easily be patched (my preference is using pytest monkeypatch). This approach would be my interpretation of developing software towards a clean code ideal. There is no need for a Dependency Injection framework or any unnecessary complex OOP-style hierarchy to accomplish it.

In addition to testability, the Python code becomes runnable and REPL-friendly. You can now refactor, develop and test-run the individual functions in the REPL. This is a very fast workflow for a developer. Read more about REPL Driven Development in Python here.

With the features living in separate isolated functions, you will likely begin to identify patterns:

"- Hey, this part does this specific thing & could be put in that namespace"

When moving code into a namespace package, the functions become reusable. Other parts of the application - or, if you have a Monorepo containing several services - can now use one and the same source code. The same rows of code, located in a single place of the repo. You will likely structure the repo with many namespace packages, each one containing one or a couple of modules with functions that ideally do one thing. It kind of sounds like the Unix philosophy, doesn't it?

This is how I try to write code on a daily basis, at work and when developing Open Source things. I use tools like SonarCloud and CodeScene to help me keep going in this direction. I've written about that before. The Open source code that I focus on these days (Polylith) has 0% Code Duplications, 0% Code Smells and about a 9.96 long-term Quality Code Scoring. The 0.04 that is left has been an active decision by me and is because of endpoints having 5+ input arguments. It makes sense for me to keep it like that there, but not in functions within the app itself where an options object is a better choice.

This aspect of Software Development is, from my point of view, very important. Even more important than the common Microservices/Events/REST/CQRS debates when Architecture is the topic of discussion. This was my Saturday afternoon reflections, and I thank you for reading this post. ☀️

^{Top Photo by Remy Gieling on Unsplash}

Python Monorepo Visualization

What's in a code repository? Usually you'll find the source code, some configuration and the deployment infrastructure - basically the things needed to develop & deploy something. It might be a service, an app or a library. A Monorepo contains the same things, but for more than one artifact. In there, you will find the code, configurations and infrastructure for several services, apps or libraries.

The main use case for a Monorepo is to share code and configuration between the artifacts (let's call them projects).

These things have to be simple

Sharing code can be difficult. Repos can be out of date. A Monorepo can be overwhelming. With or without a Monorepo, the most common way of sharing code is to package them as libraries that the projects can add as external dependencies. But managing different versions and keeping the projects up-to-date could lead to unexpected and unwanted extra work. Some Monorepos solve this by using symlinks to share code, or custom scripts for copying things into the individual projects during deployment.

Doing that can be messy, I've seen it myself. I was once part of a team that migrated away from a horrible Monorepo, into several smaller single-repo microservices. The tradeoffs: source code spread out in repos with an almost identical structure. Almost is the key here. Also, code and config duplications.

These tradeoffs have a negative impact on the Developer Experience.

The Polylith Architecture has a different take on organizing and sharing code, with a nice developer experience. These things have to be simple. Writing code should be fun. Polylith is Open Source, by the way.

The most basic type of visualization

In a Polylith workspace, the source code lives in two folders named bases and components. The entry points are put in the bases folder, all other code in the components folder. At first look, this might seem very different from a mainstream Python single-project structure. But it isn't really that different. Many Python projects are using a src layout, or have a root folder with the same name as the app itself. At the top, there's probably an entry point named something like app.py or maybe main.py? In Polylith, that one would be put in the bases folder. The rest of the code would be placed in the components folder.

  components/
     .../
       auth
       db
       kafka
       logging
       reporting
       ...


You are encouraged to keep the components folder simple, and rather put logically grouped modules (i.e. namespace packages) in separate components than nested structures. This will make code sharing more straightforward than having a folder structure with packages and sub-packages. It is also less risk of code duplication with this kind of structure, because the code isn't hidden in a complex folder structure. As a side effect, you will have a nice overview over the available features: the names of the folders will tell what they do and what's available for reuse. A folder view like this is surprisingly useful.

Visualize with the poly tool

Yes, looking at a folder structure is useful, but you would need to navigate the actual source code to figure out where it is used and which dependencies that are used in there. Along with the Polylith Architecture there is tooling support. For Python, you can use the tooling together with Poetry, Hatch, PDM or Rye.

The poly info command, an overview of code and projects in the Monorepo.

Besides providing commands for creating bases, components and projects there are useful visualization features. The most straightforward visualization is probably poly info. Here, you will get an overview of all the bricks (the logically grouped Python modules, living in the bases and components folders), the different projects in the Workspace and also in which projects the bricks are added.

Third-party libraries & usages

There's a command called poly libs that will display the third-party dependencies that are used in the Workspace (yes, that's what the contents of the Monorepo is called in Polylith). It will display libraries and the usages on a brick-level. In Polylith, a brick is the thing that you share across projects. Bricks are the building blocks of this architecture.

The poly libs command, displaying the third-party dependencies and where they are used.

The building blocks and how they depend on each other

A new thing in the Python tooling is the command called poly deps. It displays the bricks and how they depend on each other. You can choose to display an overview of the entire Workspace, or for an individual project. This kind of view can be helpful when reasoning about code and how to combine bricks into features. Or inspire a team to simplify things and refactor: should we extract code from this brick into a new one here maybe?

A closer look at the bricks used in a project with poly deps.

You can inspect a single brick to visualize the dependencies: where it is used, and what other bricks it uses.

A zoomed-in view, to inspect the usages of a specific brick.

Export the visualizations

The output from these commands is very easy to copy-and-paste into Documentation, a Pull Request or even Slack messages.

poly deps | pbcopy

📚 Docs, examples and videos

Have a look at the the Polylith documentation for more information about getting started. You will also find examples, articles and videos there for a quick start.

^{Top image made with AI (DALL-E) and manual additions by a Human (me)}

Simple & Developer-friendly Python Monorepos

🎉 Announcing new features 🎉

Polylith is about keeping Monorepos Simple & Developer-friendly. Today, the Python tools for the Polylith Architecture has support for Poetry, Hatch and PDM - three popular Packaging & Dependency Management tools in the Python community.

In addition to the already existing Poetry plugin that adds tooling support for Polylith, there is also a brand new command line tool available. The CLI has support for both Hatch and PDM. You can also use it for Poetry setups (but the recommended way is to use the dedicated Poetry plugin as before).

To summarize: it is now possible to use the Simple & Developer-friendly Monorepo Architecture of Polylith with many different kinds of Python projects out there.

"Hatch is a modern, extensible Python project manager."
^{From the Hatch website}

🐍 Hatch

To make the tooling fully support Hatch, there is a Hatch build hook plugin to use - hatch-polylith-bricks - that will make Hatch aware of a Polylith Workspace. Hatch has a nice and well thought-through Plugin system. Just add the hook to the build configuration. Nice and simple! The Polylith tool will add the config for you when creating new projects:

[build-system]
requires = ["hatchling", "hatch-polylith-bricks"]
build-backend = "hatchling.build"

"PDM, as described, is a modern Python package and dependency manager supporting the latest PEP standards. But it is more than a package manager. It boosts your development workflow in various aspects."
^{From the PDM website}

🐍 PDM

Just as with Hatch, there are build hooks available to make PDM aware of the Polylith Workspace. Writing hooks for PDM was really simple and I really like the way it is developed. Great job, PDM developers! There is a workspace build hook - pdm-polylith-workspace - and a projects build hook - pdm-polylith-bricks - to make PDM and the Polylith tooling work well together.

This is added to the workspace build-system section pyproject.toml:

[build-system]
requires = ["pdm-backend", "pdm-polylith-workspace"]
build-backend = "pdm.backend"

And the plugin for projects.
This will be added by the poly create project command for you.

[build-system]
requires = ["pdm-backend", "pdm-polylith-bricks”]
build-backend = "pdm.backend"

"Python packaging and dependency management made easy."
^{From the Poetry website}

🐍 Poetry

For Poetry, just as before, add or update these two plugins and you're ready to go!

poetry self add poetry-multiproject-plugin
poetry self add poetry-polylith-plugin

📚 Docs, examples and videos

Have a look at the the Polylith documentation for more information about getting started. You will also find examples, articles and videos there for a quick start. I'm really excited about the new capabilities of the tooling and hope it will be useful for Teams in the Python Community!

^{Top photo made with AI (DALL-E) and manual additions by a Human (me)}
